Topcon OPUS A8s
The OPUS A8s is the large keyed A-series HMI for demanding operator consoles. It combines a 12.1 inch display with physical controls for machine interfaces where visibility and tactile operation both matter.
Topcon OPUS A8s front view 1/4
Highlights
- Display: 12.1 in, 16:10 TFT transmissive; 1280 x 800 px, 1000 cd/m2; Contrast ratio 750:1
- Operator controls: 8 softkeys; 4 hardkeys; Encoder; Touchscreen
- Interfaces: 2 x CAN-Bus ISO 11898; CAN specification 2.0 B active; 1 x RS232 (only RxD, TxD, GND); Ethernet 10/100 Mbit/s Base T...
- Rugged rating: operating -30 to +65 deg C, storage -40 to +85 deg C, IP65/IP66 protection
- Protocols: CANopen; CANfreestyle; J1939
Technical data
- Display
- 12.1 in, 16:10 TFT transmissive; 1280 x 800 px, 1000 cd/m2; Contrast ratio 750:1
- User interface
- 8 softkeys; 4 hardkeys; Encoder; Touchscreen
- Processor
- 32-bit, 1 GHz; NXP I.MX6 quad
- Operating system
- Linux Kernel 4.0.0 or higher
- Memory
- 1 GB DDR2 RAM; 8 GB NAND flash
- Interfaces
- 2 x CAN-Bus ISO 11898; CAN specification 2.0 B active; 1 x RS232 (only RxD, TxD, GND); Ethernet 10/100 Mbit/s Base T; Analog/Digital I/O: 4 analog/digital inputs; 3 digital outputs; 1 USB 2.0 high speed on main connector; 1 USB 2.0 high speed on front
- Supported protocols
- CANopen; CANfreestyle; J1939
- Power supply
- 9 to 36 V DC
- Environmental conditions
- operating -30 to +65 deg C; storage -40 to +85 deg C; Protection: IP65/IP66; Mechanical Shock: Level 2; Random Vibration: Level 2; Sinusoidal Vibration: Level 2
- Housing
- Orientation landscape or portrait; W376 x H214 x D76 mm; excl. connector and cables
- Sensors and indicators
- Light sensor; Multicolor-LED; 3 Status-LEDs
- Audio
- 1 x Audio output (left, right, GND); Output power: approx. 65 mW @32 Ohm; Speaker, approx. 80 dB(A)
- Connectors
- Main: AMP Seal, 26 pin; Video: M12 round, 5 pole, B-coded; Ethernet: M12 round, 4 pole, D-coded
